10x10 Trade Show Exhibit Display Booth | EVT290S-Auburn

10x10 Trade Show Exhibit Display Booth | EVT290S-Auburn

Original price was: $14,648.00.Current price is: $7,324.00.

10x10 Trade Show Truss Booth | Aluminum Square Truss Display Kit

Dimensions & Specs
Footprint: 10 ft x 10 ft (3.04 m x 3.04 m)
Overall Height: 9.97 ft (3.03 m)
Truss Profile: 11.41 in (290 mm) Square Truss
Coverage: ~100 sq ft
Type: Modular Square Truss System

Construction
Material Type: Aluminum Alloy EN AW-6082 T6
Main Tubing: 1.96 in (50 mm) OD / 0.08 in (2 mm) Wall Thickness
Brace Tubing: 0.78 in (20 mm) Diagonal Bracing / 0.08 in (2 mm) Wall Thickness
Connection Type: Conical Connection System (Includes Couplers, Tapered Pins, and R-Clips)

Finish & Features
Surface: Aluminum Brush Finish
Certification: TUV Certified
Compatibility: Fits all standard 290mm / F34 Truss Systems
Weight: 376 lb (170.55 kg)

In stock

SKU: EVT290S-TSB-10x10-AUBURN Categories: ,

EVT290S Square Booth System Knowledge Center

10 x 10 Truss Exhibit Booth.
Four Configurations from One Truss System.

The EVT290S-Auburn is a modular 10 x 10 ft exhibit system built from EVT290S 290 mm square aluminum truss. One component set assembles into four different booth configurations: open-front, deeper overhead frame, portal-style, and stepped profile. The kit includes the truss components and 8 complete sets of conical connecting hardware, with couplers, tapered pins, and R-clips. Choose one configuration for each installation.

System Facts

ModelEVT290S-Auburn
SKUEVT290S-TSB-10x10-AUBURN
Base Booth Footprint9.84 x 9.84 ft / 3 x 3 m
Overall Height9.97 ft / 119.68 in
Truss Profile11.42 in / 290 mm Square
System Weight376 lb / 170.55 kg
4 ConfigurationsOptions from One System
10 x 10 ftBooth Class
9.97 ftOverall Height
290 mmSquare Truss Profile
8 SetsConnecting Hardware Included

System Overview

A Reusable Square Truss Exhibit System with Four Customer-Facing Configuration Options.

The EVT290S-Auburn is built around EVT290S 290 mm square truss with four 50 mm main chords. The component set builds any one of four supplied configurations rather than one fixed shape. The square profile gives multiple faces for compatible display and branding elements, while the chosen configuration sets the placement of uprights, overhead truss, access openings, and attachment locations.

Four Assembly Options
One component set can be assembled into four visually distinct booth configurations.
One System per Installation
Choose one configuration for each installation. The kit does not include four separate booths and cannot build all four arrangements at the same time.
10 x 10 Exhibit Class
Built around a 9.84 x 9.84 ft / 3 x 3 m base booth footprint for compact exhibit spaces.
Reusable Component System
The system can be disassembled, transported, and rebuilt in the chosen supplied configuration for future events.

Four Configuration Options

Choose the Arrangement That Fits the Space, Traffic Flow, and Brand Presentation.

One EVT290S-Auburn component set provides four display configurations, from a broad open-front portal and a deeper overhead frame to stepped or asymmetrical truss profiles. This lets customers choose the presentation that fits their event.

Open-Front Presentation
A broad, accessible front opening supports direct customer sightlines, reception placement, product interaction, and branded presentation.
Deeper Overhead Framing
A more developed overhead arrangement provides a stronger enclosed-frame appearance for graphics, lighting, and displays.
Portal-Style Structure
A clean upright-and-header arrangement creates a focused entry or branded gateway presentation.
Stepped Visual Profile
A stepped or asymmetrical profile provides visual variation where the booth concept calls for an elevated feature or non-uniform silhouette.
The kit provides four alternate configuration options from one component set. Select one configuration per installation.
The four options are not four separate booth kits and are not intended to be assembled simultaneously from the same included components.
The configuration options do not establish configuration-specific attachment capacity, independent load ratings, ballast requirements, or anchoring requirements.

Common Applications

Designed for Trade Shows and Branded Environments.

The EVT290S-Auburn creates a defined exhibit framework for 10 x 10 booth spaces and temporary branded environments. Select one of the four configurations for graphics, signage, product demonstrations, lighting, sponsor areas, and promotional displays when the attachments and final structure are reviewed for the event conditions.

Trade Show Exhibits
Create a branded truss framework for a 10 x 10 exhibit space.
Product Displays
Frame approved product demonstrations, graphics, display counters, and promotional elements.
Branded Activations
Support banners, graphics, lighting, and branded visual elements using suitable attachment methods.
Temporary Retail and Events
Build reusable pop-up, sponsor, registration, hospitality, and promotional environments.

Included with the System

EVT290S Components and 8 Complete Sets of Connecting Hardware.

The system includes the EVT290S truss components and 8 complete sets of conical connecting hardware used across the four configuration options. Each set includes the required couplers, tapered pins, and R-clips for the system’s connection points. A small steel hammer is required to seat and remove tapered pins. Verify that all eight hardware sets and all delivered truss components are present, undamaged, and match the current order and packing list before installation.

EVT290S Truss Components
The square aluminum truss components used to assemble one selected booth configuration.
8 Conical Connection Sets
Eight complete connecting-hardware sets are included for the selected configuration.
Couplers, Pins, and R-Clips
Each included connection set contains the required couplers, tapered pins, and R-clips.
Small Steel Hammer Required
Use a small steel hammer to seat and remove tapered pins in a controlled manner.

Technical Reference

Complete System Specifications.

Identification

System Details

ModelEVT290S-Auburn
SKUEVT290S-TSB-10x10-AUBURN
BrandEvolve Truss
System Type10 x 10 Square Aluminum Truss Booth System
Assembly Configurations4 Configurations from One System

Dimensions and Weight

Base System Reference

Base Booth Footprint9.84 x 9.84 ft / 3 x 3 m
Overall Width9.97 ft / 119.68 in
Overall Depth9.94 ft / 119.29 in
Overall Height9.97 ft / 119.68 in
System Weight376 lb / 170.55 kg

Truss Construction

EVT290S System

Truss ProfileEVT290S 11.42 in / 290 mm Square
MaterialEN AW-6082 T6 Aluminum Alloy
Main Chords1.96 in / 50 mm OD, 0.08 in / 2 mm Wall
Brace Tubing0.79 in / 20 mm Diagonal, 0.08 in / 2 mm Wall
FinishBrushed Aluminum
CompatibilityEVT290S, F34, and Standard 290 mm Square Truss Systems

Assembly and Support

System Requirements

Connection SystemConical Couplers, Tapered Pins, and R-Clips
Included Hardware8 Complete Sets of Couplers, Tapered Pins, and R-Clips
Assembly ToolSmall Steel Hammer
Clamp CompatibilityStandard 50 mm / 2 in Clamps
CertificationTÜV Certified
Warranty1-Year Limited Manufacturing-Defect Warranty

System Compatibility

EVT290S, F34, and Standard 290 mm Square Truss Systems.

The EVT290S-Auburn uses 290 mm square truss, 50 mm main chords, and a conical connection system. It is compatible with EVT290S, F34, and standard 290 mm square truss systems that use matching conical connection hardware. Confirm the complete connection and resulting structure before combining separately sourced components.

EVT290S Compatibility
Integrates with EVT290S straight sections, corners, and expansion components.
F34 Compatibility
Compatible with F34 290 mm square truss and matching conical hardware.
Matching Conical Hardware
Connections to other 290 mm square truss systems use matching conical receivers and connection hardware.
50 mm Clamp Compatibility
The 50 mm main chords accept compatible, properly rated standard 50 mm or 2 in clamps. Confirm the clamp, its attachment method, and the installed loads before use.

Assembly Overview

Choose the Configuration First. Then Build the Selected System in a Controlled Sequence.

The system is typically assembled by three to four people using a small steel hammer for the tapered-pin conical connections. Select one of the four supplied configurations before organizing components. Confirm all eight connecting-hardware sets are present, then inspect the crown, bases, vertical supports, attachments, ballast or anchoring, and venue clearances as one completed system before use.

01 — Select One Configuration
Choose the configuration that fits the event footprint, traffic flow, visual presentation, and approved attachment method. Do not attempt to build all four from one kit.
02 — Organize Components
Lay out the required straight sections, corners, bases, and all 8 connection sets for the selected configuration.
03 — Build Ground-Level Assemblies
Assemble overhead or frame sections at floor level in accordance with the selected supplied configuration.
04 — Position Bases and Supports
Position base components and vertical supports according to the selected configuration and approved floor and support drawing.
05 — Lock Every Connection
Verify all 8 coupler, tapered-pin, and R-clip connection sets are fully seated and retained.
06 — Final Inspection
Confirm plumb, level, ballast or anchoring, clearances, attachment security, and venue requirements before service.

Safety and Engineering

Each Configuration Changes How the Booth Is Built. Evaluate the Completed Booth as One System.

The 376 lb / 170.55 kg system weight is a product fact, not a universal anchoring or ballast design. Each of the four configuration options changes the placement of uprights, overhead truss, access openings, and potential attachment points. Final capacity and stability depend on the selected configuration, attached signs, graphics, monitors, lighting, shelving, overhead elements, rigging points, ballast, anchoring, floor conditions, venue rules, and operating environment.

Select one configuration before choosing graphics, fixtures, display attachments, ballast, anchoring, and public-access controls.
Before assembly, verify that all 8 connecting-hardware sets are present, undamaged, and matched to the selected configuration.
Use only complete, undamaged EVT290S-compatible components, conical couplers, tapered pins, R-clips, and approved connection hardware.
Do not apply loads directly at truss connections unless specifically permitted by the applicable engineering data and installation procedure.
Evaluate graphics, monitors, lighting, shelving, product displays, and every suspended or attached element for the selected configuration before installation.
Provide ballast, anchoring, bracing, barriers, or other stability measures suitable for the selected configuration and venue conditions.
Confirm floor loading, surface condition, egress, overhead clearance, fire and venue requirements, and public-access controls before use.
Inspect every tapered pin and R-clip in all 8 included sets for full engagement before any load is applied or the booth is opened to attendees.

Evidence and Review

What Is Confirmed, and What Your Selected Configuration Must Still Establish.

The EVT290S-Auburn offers four alternate booth configurations from one component set, uses 290 mm square EN AW-6082 T6 truss, includes 8 sets of connecting hardware, and has a 9.84 x 9.84 ft base footprint, a 9.97 ft / 119.68 in height, and a 376 lb system weight. These facts do not establish independent dimensions, attachment capacity, ballast, anchoring, fixture selection, venue approval, or final stability for each individual configuration.

Confirmed System Facts
Four alternate configuration options from one component set, 290 mm square aluminum truss, 8 conical connection sets, a 9.84 x 9.84 ft base booth footprint, 9.97 ft / 119.68 in overall height, and 376 lb system weight.
Configuration-Specific Facts
The selected configuration’s component positions, attachment locations, graphics, lighting, displays, ballast, anchoring, bracing, and floor-use requirements must be determined for the actual event.
Evidence Worth Retaining
Keep the selected configuration image or drawing, bill of materials, 8-set hardware check, attachment drawing, ballast or anchoring details, inspection record, assembly photos, and required venue approvals with the project file.
Clamp and Accessory Selection
The 50 mm chords accept standard 50 mm or 2 in clamps. Confirm the clamp’s rating and attachment method for your application before relying on it.

System Questions

Frequently Asked Questions.

How many booth configurations can the EVT290S-Auburn create?

Four. One component set can be assembled into an open-front presentation, a deeper overhead frame, a portal-style structure or a stepped profile. You build one configuration per installation, because the kit is one booth and cannot build all four at the same time.

What is included, and what do I need to assemble it?

The system includes the EVT290S truss components and 8 complete sets of conical connecting hardware, each with couplers, tapered pins and R-clips. You need a small steel hammer to seat and remove the tapered pins, and a crew of three to four people.

How big is the booth, and how much does it weigh?

The base footprint is 9.84 x 9.84 ft / 3 x 3 m, built for a 10 x 10 exhibit space, with an overall height of 9.97 ft / 119.68 in. The system weighs 376 lb / 170.55 kg, which is a product fact and not a ballast or anchoring calculation for your configuration.

Will it work with other 290 mm truss, and what clamps fit?

Yes. It is compatible with EVT290S, F34, and standard 290 mm square truss systems that use matching conical connection hardware, so you can expand the booth with additional EVT290S components. The 50 mm main chords accept standard 50 mm or 2 in clamps, and STEP and DWG files are available upon request.

Need a reusable 10 x 10 exhibit system with configuration flexibility?

Contact us for support selecting one of the four configuration options, graphics and lighting selection, additional EVT290S components, CAD resources, connection-hardware guidance, engineering coordination, and quantity pricing.

Contact UsRequest a Quote

Structural Solutions, Unmatched Innovation

Weight 376 lbs
Dimensions 120 × 120 × 120 in
MANUFACTURER

Evolve Truss
TRUSS SERIES

EVT290S
