EVT290A-CS60 Black

EVT290A-CS60 Black

Original price was: $50.00.Current price is: $35.00.

EVT290A-CS60 Black | Coupler Spacer 60mm / 2.36 in (Matte Black)

Dimensions & Specs
Spacer Length: 2.36 in (60 mm)
Tube Diameter: 1.96 in (50 mm) OD
Function: Allows expansion and adjustment to custom measurements
Type: Coupler Spacer

Construction
Material Type: Aluminum Alloy EN AW-6061 T6
Compatibility: Compatible with standard 290mm Truss systems

Finish & Features
Surface: Matte Black Powder Finish
Weight: 0.99 lb (0.45 kg)

In stock

SKU: EVT290A-CS60-Black Categories: , , ,

EVT290S Truss Systems Knowledge Center

EVT290A-CS60 Black 60 mm Male Truss Coupler Spacer.
Adds 60 mm at One Compatible 290 mm Conical Truss Connection.

The EVT290A-CS60 Black is a matte black, double-ended male conical aluminum spacer that adds a fixed 60 mm / 2.36 in at one compatible 290 mm truss connection. It is identified for a 50 mm / 1.96 in tube interface. The matte black powder coat is a finish selection for exposed truss; it does not change the component's structural role. It is not a truss section, independent support point, or direct load-attachment location.

Product Facts

Model / SKUEVT290A-CS60-Black
Product TypeDouble-Ended Male Conical Coupler Spacer
Added Length60 mm / 2.36 in
Tube Interface50 mm / 1.96 in
FinishMatte Black Powder Coat
Component Weight0.99 lb / 0.45 kg
60 mmLength Added
50 mmTube Outside Diameter
Matte BlackPowder-Coat Finish
0.99 lbComponent Weight
Not IncludedPins and R-Clips

What It Is

A 60 mm Coupler Spacer with a Matte Black Finish.

This is the matte black version of the 60 mm spacer. Its functional role remains a fixed 60 mm addition at one compatible truss connection. The black finish supports visual continuity on truss that remains exposed to view.

Fixed 60 mm Collar
Adds 60 mm / 2.36 in; it does not provide adjustable travel.
Male-to-Male Form
Provides double-ended male conical interfaces for compatible receivers.
50 mm Tube Interface
Identified for 50 mm / 1.96 in tubing in compatible conical systems.
Connection Component
It is not a truss section, support point, or direct load-attachment location.

Finish Context

Finish Is a Selection Attribute. It Is Not a Structural Difference.

Choose this variant when a verified connection requires 60 mm and an exposed brushed aluminum spacer would be visually inconsistent with the surrounding truss. The finish does not alter connection requirements, load limits, or engineering requirements.

What the Spacer Supports

Match the Finish Where the Truss Stays Exposed to View.

Use the CS60 Black at the same verified connection points as the brushed CS60 where completed truss remains exposed. Confirm the 60 mm requirement, receivers, coupler, pins, r-clips, engagement, support conditions, and engineering requirements before modifying any connection.

Theater and Club Infrastructure
For planned exposed black truss in theatrical and live-production environments.
Studio Systems
For black technical frames around planned lighting, camera, sensor, and set structures.
Houses of Worship
For black truss in planned lighting, audio, video, and display structures.
Exhibits and Retail
For exposed black truss assemblies in branded exhibit and retail environments.

Selection Guidance

The Required Dimension Comes First. The Finish Must Also Match the Installation.

Select this product only when the connection requires 60 mm / 2.36 in, the black finish is required, and the complete joint remains fully engaged with compatible receivers, conical couplers, coupler-pins, and r-clips. Do not use it as an adjustable fitting or substitute for another measured requirement.

Included Components

One Matte Black Spacer. Retaining Hardware Sold Separately.

The CS60 Black ships as one double-ended male conical spacer with a matte black powder-coat finish. Coupler-pins, r-clips, and other retaining hardware are not included.

1 Male-to-Male Spacer
One double-ended male conical spacer inserts between compatible truss receivers.
60 mm Length Added
Adds 60 mm / 2.36 in at the selected connection point.
Matte Black Finish
EN AW-6061 T6 aluminum spacer with matte black powder coat.
No Retaining Hardware
Pins and r-clips must be selected for the verified connection.

Technical Reference

EVT290A-CS60 Black Specifications.

Identification

Product Details

Model / SKUEVT290A-CS60-Black
Product TypeDouble-Ended Male Conical Coupler Spacer
Weight0.99 lb / 0.45 kg

Dimensions

Size

Spacer Length60 mm / 2.36 in
Tube Interface50 mm / 1.96 in
Documented Dimensions50 x 140 x 50 mm

Construction

Material and Finish

MaterialAluminum Alloy EN AW-6061 T6
FinishMatte Black Powder Coat
Included HardwareNone, Pins and R-Clips Not Included

System Compatibility

Compatible 290 mm Conical Systems. Confirm the Actual Connection Before Use.

The CS60 Black is designed for 50 mm / 1.96 in tubing within compatible 290 mm conical-connector truss systems. Confirm actual receiver spacing, coupler dimensions, chord dimensions, pin length, retaining hardware, and the complete structural plan before use.

Mechanical fit does not establish structural suitability.

Verify all interfaces, documentation, hardware, and project-specific engineering before use.

Installation Overview

Confirm the Black 60 mm Joint Before It Enters Service.

01 — Confirm Requirement
Confirm the 60 mm addition and black-finish requirement.
02 — Inspect Components
Do not use damaged or incompatible parts.
03 — Test-Fit the Joint
Confirm complete engagement of receivers, couplers, pins, and retainers.
04 — Secure and Inspect
Install all required hardware fully before loading or lifting.

Safety and Engineering

The Black Finish Does Not Change the Structural Boundaries.

The CS60 Black does not independently establish a load rating. Do not exceed the capacity of the spacer or the modified truss system, and do not support loads directly from the spacer connection unless an exact approved load case permits it.

Verify full conical coupler engagement and suitable pin and retainer selection.
Do not stack spacers without project-specific engineering approval.
Use qualified rigging or engineering review for load-bearing or regulated structures.

Product Questions

EVT290A-CS60 Black Questions.

What is different about the Black CS60?

It has the same 60 mm / 2.36 in dimensional function as the brushed aluminum CS60, finished in matte black powder coat for exposed truss.

Are coupler-pins included?

No. Coupler-pins and r-clips must be selected separately for the completed verified connection.

Can I hang from this joint?

No. Do not support loads directly from the spacer connection.

Need a Black-Finish 60 mm Spacer for 290 mm Truss?

Contact us for black-truss compatibility checks, hardware guidance, measurement review, quantities, and engineering coordination.

Contact UsRequest a Quote

Structural Solutions, Unmatched Innovation

Weight 0.99 lbs
Dimensions 2 × 2 × 2 in
