EVT50A-S210

EVT50A-S210

Original price was: $63.00.Current price is: $42.00.

EVT50A-S210 | Female Truss Spacer 210mm / 8.26 in

Dimensions & Specs
Spacer Length: 8.26 in (210 mm)
Tube Diameter: 1.96 in (50 mm) OD
Wall Thickness: 0.08 in (2 mm)
Function: Allows expansion and adjustment to custom measurements
Type: Female Spacer

Construction
Material Type: Aluminum Alloy EN AW-6061 T6
Compatibility: Compatible with standard 50mm (2-inch) truss tubing

Finish & Features
Surface: Aluminum Brush Finish
Weight: 1.53 lb (0.69 kg)

In stock

SKU: EVT50A-S210 Categories: , , ,

EVT290S Conical Truss System Knowledge Center

EVT50A-S210 210 mm / 8.26 in Female Truss Spacer.
A Female-to-Female Spacer for 50 mm Tubing and Modular 290 mm Conical Truss Builds.

The EVT50A-S210 is a 210 mm / 8.26 in female-to-female aluminum truss spacer for compatible 50 mm / 2 in tubing and 290 mm conical truss systems. Its receiver holes create a fixed spacing bridge between adjoining compatible female truss ends. The spacer changes connection geometry at one joint; it is not a truss section, independent support point, or direct load-attachment location. Connecting hardware is not included; verify fit, full coupler seating, pin engagement, retention, and the complete engineered structure before lifting or applying load.

Product Facts

Model / SKUEVT50A-S210
Product ClassFemale Truss Spacer
Fixed Spacing210 mm / 8.26 in
Connection FormFemale-to-Female Conical Receivers
Tube Interface50 mm / 2 in Tubing
FinishBrushed Aluminum
210 mmFixed Spacing
8.26 inFixed Spacing
50 x 210 x 50 mmDocumented Dimensions
50 mmTube Interface
1.53 lbProduct Weight

Product Overview

A 210 mm Female Spacer for One Compatible 50 mm Tube and 290 mm Conical Truss Connection.

The S210 is a female-to-female spacer with receiver holes at both ends. It creates a fixed 210 mm / 8.26 in spacing bridge in a compatible 50 mm tubing and 290 mm conical truss assembly. The female receiver configuration interfaces with compatible conical connection hardware.

Fixed 210 mm Spacing
Adds a fixed bridge at one selected connection; it does not provide adjustable travel or telescoping length.
Female-to-Female Receivers
Receiver holes interface with compatible conical hardware and adjoining female truss receivers.
Brushed Aluminum Finish
Designed to visually integrate with standard aluminum truss components.
Connection-Level Component
Changes one joint; it is not a truss section, support point, or direct load-attachment location.

What It Changes

It Adds 210 mm at One Joint. It Does Not Establish a New Structural Rating.

When installed in a compatible conical connection, the spacer creates a fixed 210 mm / 8.26 in bridge. It does not independently establish allowable span, load capacity, pick-point location, support arrangement, or approval for the modified structure. Evaluate the complete system after connection geometry changes.

Selection Guidance

Select the S210 When The Layout Requires a 210 mm Female-to-Female Bridge.

Use the S210 when a documented layout requires a fixed 210 mm / 8.26 in spacing bridge between compatible female truss ends and a female-to-female receiver configuration. Do not use it as an adjustable fitting, generic extension, repair for damaged truss, or substitute for another measured correction.

Technical Reference

EVT50A-S210 Product Specifications.

Identification

Product Details

Model / SKUEVT50A-S210
BrandEvolve Truss
Product TypeFemale Truss Spacer
Connection FormFemale-to-Female Conical Receivers

Dimensions and Weight

Physical Reference

Fixed Spacing / Spacer Length210 mm / 8.26 in
Documented Dimensions50 x 210 x 50 mm
Tube Interface50 mm / 1.96 in OD
Tubing Wall Thickness2 mm / 0.08 in
Weight1.53 lb / 0.69 kg

Construction

Material and Finish

MaterialEN AW-6061 T6 Aluminum Alloy
FinishBrushed Aluminum
Functional Output210 mm Female-to-Female Spacing Bridge

Hardware

Required per Connection

Included HardwareNone
Conical Coupler1 Compatible Coupler Required
Coupler Pins2 Required
R-Clips2 Required

System Compatibility

F34, EVT290S, and Compatible 290 mm Conical Truss Systems.

The S210 is designed for compatible 50 mm / 2 in tubing and 290 mm conical-connector truss systems, including F34 and EVT290S. Before mixing brands or separately sourced components, verify receiver spacing, conical-coupler dimensions, chord geometry, pin alignment, full seating, and the complete structural plan.

Installation Checks

Confirm the 210 mm Requirement. Then Verify the Complete Connection.

01 — Confirm Correction
Confirm that the approved layout requires a fixed 210 mm bridge.
02 — Inspect Receivers
Inspect the spacer and adjoining receiver for damage, deformation, wear, or elongation.
03 — Confirm Hardware
Select hardware required for the compatible system and completed connection.
04 — Test-Fit
Confirm the compatible connection seats fully without forcing.
05 — Install Retainers
Install all pins and retention hardware required by the completed connection.
06 — Inspect Structure
Verify the completed connection and surrounding structure before loading or lifting.

Safety and Engineering

The Spacer Changes Connection Geometry. It Does Not Override System Limits.

The S210 is a structural connection component. It does not independently establish a load rating for the modified structure. Do not exceed the capacity of the spacer or modified truss system. Do not support loads directly from the spacer connection point. Review the complete structure for the actual installation.

Do not attach or support loads directly from the spacer connection point.
Do not use the spacer to force a misaligned connection or compensate for damaged truss.
Verify full seating in both receivers and install all required pins and retainers.
Do not stack or combine spacers unless the exact complete structure is approved.
Test-fit mixed-brand components on the ground before lifting.

Product Questions

Frequently Asked Questions.

What does the EVT50A-S210 do?

It creates a fixed 210 mm / 8.26 in female-to-female spacing bridge in a compatible conical truss connection.

Is connecting hardware included?

No. Select the compatible coupler, two pins, and two r-clips required for the completed connection.

What are its documented dimensions?

The listed dimensions are 50 x 210 x 50 mm, with a fixed 210 mm / 8.26 in spacing or overall length.

Can it be used as a load point?

No. Do not attach or support loads directly from the spacer connection point.

How much does it weigh?

The listed product weight is 1.53 lb / 0.69 kg.

Need to Create a 210 mm Bridge in a 50 mm Tube or 290 mm Conical Truss Layout?

Contact us for product identification, connection-hardware planning, layout review, spacer quantities, technical drawings, and engineering coordination.
