EVT220T-Alpine — 10x10 Light-Duty Triangular Aluminum Truss Booth

The EVT220T-Alpine is a 10x10 triangular aluminum truss booth built on the EVT220T 220mm (8.66 in) triangular truss series — a system engineered for operators who need a structurally sound overhead presence that reads as architecturally considered rather than generic booth infrastructure. Where square box truss creates a utilitarian grid overhead, the triangular profile delivers distinct angular geometry visible from every approach angle, making the structure itself part of the brand presentation. Fabricated from EN AW-6082 T6 aluminum alloy with a brushed aluminum finish, the Alpine assembles to a 9.84 ft x 9.84 ft x 9.84 ft cube using a conical connection system — a steel hammer is the only tool required. All couplers, tapered pins, and R-clips are included. Total system weight is approximately 160 lb (72.57 kg), sized to fit in a standard cargo van and move without a large crew.

Modular Expansion and Configuration Flexibility

The EVT220T-Alpine is a starting point, not a fixed structure. Because every component belongs to the standard EVT220T series, the booth reconfigures and grows as activation needs change:

• Extend the footprint: Insert 0.5m, 1.0m, or 2.0m straight segments to stretch the booth into a 10x20 or adjust ceiling height for venues with different clearance requirements.
• Reorient the profile: The triangular chord accepts apex-up, apex-down, or apex-in mounting orientations — each creating a distinct visual line that square truss geometry cannot produce.
• Expand your inventory: Every piece integrates with the full EVT220T catalog, so components purchased today extend your rigging inventory for future builds.

Who It's For

• Mobile entertainment and small event production companies: You're running corporate parties, outdoor festivals, and private events as a solo operator or small crew. The Alpine loads into a cargo van, assembles with a hammer and no specialized tools, and puts a premium triangular canopy overhead in a fraction of the time a standard square truss system would require — and it looks nothing like the competition's rental booth next door.
• Craft beer, spirits, and food brand pop-up teams: Your activation at a farmers market, festival, or retail parking lot needs a booth that goes up fast, looks architecturally considered, and doesn't resemble a fabric tent. The triangular overhead structure adds visual weight that fabric systems can't deliver, and when the brand outgrows the 10x10 footprint at a major activation, you add straight sections and expand without buying a new system.
• Gaming, esports, and tech brand event teams: At gaming conventions, esports competitions, and product launch activations, your booth overhead needs to signal intentional design — not off-the-shelf infrastructure. The apex-up, apex-down, or apex-in orientation options let you build a geometric visual identity. Monitor mounts, lighting arrays, and branded signage integrate cleanly using 35mm clamps, keeping the finished build organized and camera-ready.
• Retail fixture and in-store display designers: When gondola fixtures don't deliver the premium aesthetic a brand zone requires, the Alpine gives you a defined 9.84 ft vertical cube within the store floor plan. The triangular chord profile contributes angular line work that distinguishes the display area from the surrounding retail floor — permanent, semi-permanent, or seasonal installations all benefit from the structural clarity the EVT220T profile delivers.

Clamp Compatibility — Read Before You Buy

The EVT220T-Alpine uses 35mm (1.37 in) diameter main chord tubing. Standard 2-inch (50mm) clamps will not fit this system. All lighting, banner, and monitor mounts must use 35mm clamps specifically sized for this truss series.

Safety and Engineering

• Load distribution: Do not exceed the specified distributed load rating of approximately 65 lb per linear foot. All loads must be distributed equally across all chords.
• Pre-use inspection: Inspect all truss segments for deformation, scoring, or damage before every assembly. Remove any compromised components from service immediately.
• Hardware seating: Confirm all couplers, tapered pins, and R-clips are fully seated and locked before applying any load.
• Tubing care: Handle segments carefully — the 35mm main tubes are lighter and thinner than 290mm series components and are more susceptible to denting under impact.
• Engineering review: A licensed professional engineer must review all custom structures, overhead lighting plots, and permanent installations prior to use.

Technical Resources and Project Support

Need load tables, CAD files, or engineering documentation for this product? Contact the Evolve Truss team — we'll get you what you need.

Disclaimer and Guidance Statement: The purchase of any product shall not be construed as authorizing or approving a specific installation or usage. A licensed professional engineer shall review all structures, lighting plots, or any other product uses. While exhaustive efforts have been undertaken to ensure the precision of this information, Evolve Truss Worldwide, LLC hereby disclaims any and all liability for errors. These drawings are intended solely for the purpose of providing guidance and should not be construed as definitive representations.
